SolPod Express Kit User Guide | Instruction Manual

Atomizer Installation Instructions:

1. Screw the magnetic adapter onto the atomizer.
2. Insert the atomizer into the battery box mod.
3. Press the button. Use it when there is continuous lighting.

Key Description:

1. Click the button 5 times to turn the SolPod on/off
2. Smart Preheat Function: Click the button 2 times to activate the preheat setting, the red light will slowly blink for 15 seconds unless the button is pressed.
3. Adjust the voltage level: Press the button 3 times quickly to adjust the voltage level. 4.1v (Red), 3.3v (Yellow), 2.6v (Green).
4. Over discharge Protection: When vaping longer than 8 seconds the LEDS will flash 6 times and the SolPod will stop outputting heat until the button is pressed again.
5. Charging Indication: The LED will indicate the corresponding capacity as following; fully green when fully charged, green >70% charge, yellow 30-70%, red is <30%.
6. No-load indication: The LED will flash 3 times with no output if it does not detect a cartridge connection.
7. No Power indication: The LED will flash 8 times and power off when out of batteries.
8. Charging port: Supports Micro-USB charging styles
9. Protection Functions: The LED will flash 3 times quickly when the atomizer detects a short circuit.

**Overheat protection: The LEDs will flash 3 times when the PCBA detects overheating.

**Overcharge protection: The SolPod automatically stops charging when fully charged.

1. Atomizer Resistance Range: 1-3.0 ohm
2. SolPod is not fully charged when leaving the factory. For best results please charge before use!
